54311-1 datasheet pdf and Terminals - Ring Connectors product details from TE Connectivity AMP Connectors stock available on our website
SOT-23
54311-1 Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Lifecycle Status
ACTIVE (Last Updated: 6 days ago)
Factory Lead Time
32 Weeks
Contact Material
Copper
Contact Plating
Tin
Mount
Stud
Mounting Type
Free Hanging (In-Line)
Material
Copper
Material - Insulation
Polyamide (PA), Nylon
Body Material
Copper
Packaging
Bulk
Series
PIDG
Published
2004
Feature
Serrated Termination
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
Crimp
Color
Yellow
Orientation
Straight
Depth
7.13mm
Contact Finish
Tin
Voltage - Rated AC
300V
Wire Gauge
24-26 AWG
Plating
Tin
Wire Gauge (Max)
24 AWG
Wire Gauge (Min)
26 AWG
Body Plating
Tin
Sealable
No
Insulation Diameter
0.050 ~ 0.105 (1.27mm ~ 2.67mm)
Insulation
Insulated
Thread Size
M4
Terminal Type
Circular
Stud/Tab Size
8 Stud
Insulated Wire Support
Yes
Heavy Duty
No
Stud Diameter
4.17 mm
Government Qualified
Yes
Stud Size
M4
Length
20.67mm
Thickness
0.027 0.69mm
Length - Overall
0.814 20.68mm
Width - Outer Edges
0.281 7.14mm
Tongue Thickness
736.6μm
REACH SVHC
No SVHC
Radiation Hardening
No
RoHS Status
RoHS Compliant
Lead Free
Lead Free
In-Stock:5836 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$1.05000
$1.05
10
$0.92500
$9.25
25
$0.87040
$21.76
50
$0.83420
$41.71
100
$0.79790
$79.79
250
$0.72532
$181.33
500
$0.65278
$326.39
54311-1 Product Details
TE Connectivity / AMP Terminals Ring Connectors 54311-1 are designed for reliable and secure electrical connections. These ring connectors are made from high-quality materials and feature a 24-26 AWG #8 crimp for a secure connection. The connectors are designed to provide superior electrical performance and are suitable for a variety of applications. They are easy to install and provide a reliable connection for a variety of applications. The connectors are UL listed and RoHS compliant, making them a safe and reliable choice for any application. With their superior performance and reliable connection, TE Connectivity / AMP Terminals Ring Connectors 54311-1 are the perfect choice for any application.
