Name: 796635-3
Brand: TE Connectivity AMP Connectors
SKU: 796635-3
Price: 1.97000 USD
Availability: InStock

new-10%

796635-3

Manufacturer part number:796635-3

Manufacturer:TE Connectivity AMP Connectors

Description:796635-3 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:796635-3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	21 Weeks
Lifecycle Status	ACTIVE (Last Updated: 5 days ago)
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Free Hanging (In-Line)
Material	Nylon
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Buchanan
Feature	Retention Latches (Non-Wire Side)
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Connector Type	Plug
Type	Plug, Female Sockets
Number of Positions	3
Color	Black
Number of Rows	1
Gender	Male
Voltage - Rated	300V
Pitch	0.200 5.08mm
Orientation	Right Angle
Depth	18.4mm
Insulation Height	0.610 15.49mm
Current Rating	15A
Termination Style	Screw - Rising Cage Clamp
Approval Agency	UL
Number of Contacts	3
Housing Color	Black
Voltage	300V
ELV	Compliant
Number of Circuits	3
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	30 AWG
Number of Poles	3
Contact Mating Finish	Tin
Voltage - UL	300V
Wire Gauge or Range - AWG	12-30 AWG
Current - UL	15A
Torque - Screw	0.79 Nm (7.0 Lb-In)
Positions Per Level	3
Plug Wire Entry	180°
Thread Size	M3
Wire Gauge or Range - mm²	0.05-3mm2
Wire Strip Length	6-7.5mm
Number of Positions Per Level	3
Screw Size	M3
Max Supply Voltage (AC)	300V
Length	15.24mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

796635-3 Product Details

796635-3 Overview

Currently, it is packaged in Plug.Free Hanging (In-Line) is the mounting type.A Bulk case is used for packaging.It's part of the Buchanan Series.A number of features make it more powerful because of its Retention Latches (Non-Wire Side) feature.Through Hole is used to mount the part.Circuits number 3 are contained in the part.Operating temperature is -40°C~110°C.As with other Plug, Female Sockets products, this part also offers a wide range of benefits.
