Name: 796640-7
Brand: TE Connectivity AMP Connectors
SKU: 796640-7
Price: 5.60000 USD
Availability: InStock

new-10%

796640-7

Manufacturer part number:796640-7

Manufacturer:TE Connectivity AMP Connectors

Description:796640-7 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:796640-7 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Contact Material	Phosphor Bronze
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Buchanan
Feature	Retention Latches (Non-Wire Side), Side Stacking
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Plug
Type	Plug, Female Sockets
Number of Positions	7
Color	Green
Number of Rows	1
Voltage - Rated	300V
Additional Feature	POLARIZED, 94V-0, PA66
HTS Code	8536.69.40.40
Pitch	0.197 5.00mm
Orientation	Right Angle
Insulation Height	0.610 15.49mm
Current Rating	15A
Termination Style	Screw - Rising Cage Clamp
Voltage - Rated AC	300V
Number of Contacts	7
Voltage	300V
ELV	Compliant
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Torque - Screw	0.79 Nm (7.0 Lb-In)
Number of Ways	18
Safety Approval	UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.05-3mm2
Wire Strip Length	6-7.5mm
Screw Size	M3
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

796640-7 Product Details

796640-7 Overview

The product is packaged in Plug.The mounting type of the device is Free Hanging (In-Line).Packaging is performed using a Bulk case.Among the products in the Buchanan Series, it is one of the most popular.Other features include POLARIZED, 94V-0, PA66, to name just a few.A number of advantages can be derived from its Retention Latches (Non-Wire Side), Side Stacking feature.It's mounted by Cable, Free Hanging.Device runs in -40°C~110°C operating temperature.There are a number of benefits that this part has in common with other Plug, Female Sockets products.
