Name: 796644-4
Brand: TE Connectivity AMP Connectors
SKU: 796644-4
Price: 1.73000 USD
Availability: InStock

new-10%

796644-4

Manufacturer part number:796644-4

Manufacturer:TE Connectivity AMP Connectors

Description:796644-4 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:796644-4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	21 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Material	Nylon
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Termi-Blok, Buchanan
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Header
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	4
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	300V
Pitch	0.197 5.00mm
Orientation	Right Angle
Depth	8.35mm
Insulation Height	0.329 8.36mm
Current Rating	15A
Termination Style	Solder
Voltage - Rated AC	300V
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	1
Current	15A
Wire Gauge (Max)	12 AWG
Wire Gauge (Min)	30 AWG
Contact Mating Finish	Tin
Number of Decks	1
Number of Ways	24
Safety Approval	UL
Header Orientation	90°, Right Angle
Number of Positions Per Level	4
Fastening Method	CONNECTOR
Length	22mm
Width	12mm
Length - Tail	3.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

796644-4 Product Details

796644-4 Overview

Packaging for this item is Header.This device's mounting type is Through Hole.The product is packaged in a Bulk case.Specifically, it is one of the products in the Termi-Blok, Buchanan Series.Through Hole is the mounting point for the part.In this case, the device runs at -40°C~110°C Operating Temperature.With this part, you get a lot of benefits that you won't find in other Header, Male Pins, Shrouded (4 Side) products.
