Name: 796858-6
Brand: TE Connectivity AMP Connectors
SKU: 796858-6
Price: 10.61000 USD
Availability: InStock

new

796858-6

Manufacturer part number:796858-6

Manufacturer:TE Connectivity AMP Connectors

Description:796858-6 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:796858-6 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Lifecycle Status	ACTIVE (Last Updated: 5 days ago)
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Free Hanging, Panel
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2007
Series	Buchanan
Feature	Mating Flange
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Connector Type	Plug
Type	Plug, Female Sockets
Number of Positions	6
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Color	Green
Number of Rows	1
Voltage - Rated	300V
Pitch	0.197 5.00mm
Orientation	Right Angle
Depth	18.4mm
Insulation Height	0.610 15.49mm
Current Rating	15A
Termination Style	Screw - Rising Cage Clamp
Voltage - Rated AC	300V
Number of Contacts	6
Housing Color	Green
Voltage	300V
ELV	Compliant
Number of Circuits	6
Max Voltage Rating (AC)	300V
Max Current Rating	15A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Voltage - UL	300V
Wire Gauge or Range - AWG	12-30 AWG
Current - UL	15A
Torque - Screw	0.79 Nm (7.0 Lb-In)
Positions Per Level	6
Plug Wire Entry	180°
Thread Size	M3
Wire Gauge or Range - mm²	0.05-3mm2
Wire Strip Length	6-7.5mm
Number of Positions Per Level	6
Screw Size	M3
Max Supply Voltage (AC)	300V
Length	39.8mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

796858-6 Product Details

796858-6 Overview

Packaging for this item is Plug.This device is mounted in the Free Hanging (In-Line) position.Packaging is performed using a Bulk case.Among the products in the Buchanan Series, it is one of the most popular.If it is to be used, it should be kept at a temperature below 105°C.There is a minimum temperature requirement of [0°C] for this device.In many ways, its Mating Flange feature makes it more powerful.You've got Free Hanging, Panel mounted on the part.Circuits number 6.Running in -40°C~110°C Operating Temperature.It shares many benefts with other Plug, Female Sockets products.
