MSP430F2112IPW Overview
A 28-TSSOP (0.173, 4.40mm Width) package is included. In total, it has 24 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 16-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~85°C TA. MSP430F2xx series components belong to this electrical component. Its program memory size is 2KB 2K x 8 + 256B. There is a MSP430 Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 28 terminations in total. The part works on a 16-bit basis. The Microcontroller chip has NO DMA channels. 2kB memory size belongs to the part. A good performance can be achieved at a frequency of 16MHz, as long as it is operated at a low power consumption. In order for the device to work with the motor, it utilizes the PWM channel YES. On the chip, there are 28 pins that are accessible. A total of 2 timers/counters are included in the package. A total of 28 pins are present. The Microcontroller has 8 A/D converters. Devices like this use an 1-channel PWM controller. There are 1 serial I/Os on the IC part.
MSP430F2112IPW Features
28-TSSOP (0.173, 4.40mm Width) package
Mounting type of Surface Mount
MSP430F2112IPW Applications
There are a lot of Texas Instruments
MSP430F2112IPW Microcontroller applications.
- Calculator
- Kindle
- Christmas lights
- 3D printers
- Washing machine
- Microwave ovens
- Home appliances
- Home video and audio
- Entertainment products
- Digital cameras
