Name: SN65LVDT14PWG4
Brand: Texas Instruments
SKU: SN65LVDT14PWG4
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-TSSOP (0.173, 4.40mm Width)
Number of Pins	20
Weight	76.997305mg
Operating Temperature	-40°C~85°C
Packaging	Tube
Series	65LVDT
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	20
ECCN Code	EAR99
Type	Transceiver
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory	Line Driver or Receivers
Technology	CMOS
Voltage - Supply	3V~3.6V
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Supply Voltage	3.3V
Terminal Pitch	0.65mm
Base Part Number	65LVDT14
Pin Count	20
Operating Supply Voltage	3.3V
Nominal Supply Current	25mA
Power Dissipation	774mW
Propagation Delay	3.8 ns
Turn On Delay Time	3.8 ns
Logic Function	Buffer
Data Rate	125Mbps
Output Characteristics	TOTEM-POLE
Differential Output	YES
Output Polarity	TRUE
Protocol	LVDS
Input Characteristics	DIFFERENTIAL
Number of Drivers/Receivers	1/4
Receiver Number of Bits	4
Duplex	Half
Number of Drivers	4
Number of Transceivers	1
Transmit Delay-Max	2.9 ns
Supply Voltage1-Nom	3.3V
Output Low Current-Max	0.008A
High Level Input Current-Max	0.00002A
Height	1.2mm
Length	6.5mm
Width	4.4mm
Thickness	1mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

SN65LVDT14PWG4 Product Details

SN65LVDT14PWG4 Overview

Driver ICs with enhanced 20-TSSOP (0.173, 4.40mm Width) packages are excellent for driving LEDs with common characteristics.In the Tube package, this receiver is mounted.Being a Transceiver can transceiver, this part has empowered many solutions to serve for a variety of applications.This wide receiver can be placed on any Surface Mount-type PCB or development board.This differential driver consumes 3V~3.6V for its power supplyDuring operation, this electronic part may have up to 1/4 eligible receivers/drivers.For applications where the operating temperature is -40°C~85°C, this ic receiver was designed primarily.Wide receiver can operate within the range of 3.3V supply voltages efficiently.Wide receiver has 20 terminations built in for driving or receiving signals from data.This transceiver is packaged with 20 market standard pinoutsThis part number 65LVDT14 can be used to search for more variants based on the product type, temperature, package, etc.An enhanced power dissipation driver IC with 20 pins.Package size is drastically reduced by downsizing ICs and mounting them in high-density Surface Mount arrays.As a rule of thumb, this receiver is typically specified with a resolution of 4 bits.This transceiver module is designed to operate from an input voltage supply of 3.3V.It is possible to subcategoriLine Driver or Receiverse this rf transceiver module as Line Driver or Receivers.The module isolated transceiver implements a total of 1 transceivers.This electronic part can have?up to 4 eligible drivers on the field at once.?An enhanced power-saving technique is implemented in this integrating circuit, whintegrating circuith is one of the 65LVDT series.
