SN74LVC1G00DPWR Overview
Packed in 4-XFDFN Exposed Pad, the part is convenient for shipping overseas. Advanced packaging method Tape & Reel (TR) is used to provide high reliability. It works based on the NAND Gate logic principle. To ensure the part's full function, a voltage of 1.65V~5.5V is needed. Extended operating temperature around -40°C~125°C. The part is mounted in Surface Mount. The high and low state of output current is 32mA 32mA. It comes from the 74LVC series. There are 4 terminations totally. The part has 1 functions that significantly boost the user experience. It represents the LVC/LCX/Z product family. If you are looking for device variants, try search with 74LVC1G00. Surface Mount mounted, this logic device is widely used in many applications. Please refer to the datasheets for 5 pins functions. The part supports 2 inputs. In the quiescent state, the part has 10μA current flowing through it. The device's output current is rated 50mA. Logical operation through 1 gates.
SN74LVC1G00DPWR Features
NAND Gate Logic Type
Operating Temperature: -40°C~125°C
LVC/LCX/Z Family
Quiescent Current: 10μA
Output Current: 50mA
1 Gates
SN74LVC1G00DPWR Applications
There are a lot of Texas Instruments
SN74LVC1G00DPWR Gates and Inverters applications.
- Air conditioner
- Home theater
- Electric grinding wheel
- Electrical tools
- Sewing machine
- DVD
- VCD
- Computer
- Television
- Washing machine
