Name: TPS74201RGRR
Brand: Texas Instruments
SKU: TPS74201RGRR
Price: 2.79000 USD
Availability: InStock

new-10%

TPS74201RGRR

Manufacturer part number:TPS74201RGRR

Manufacturer:Texas Instruments

Description:Enable, Power Good, Soft Start Adjustable 0.5mm TPS74201 PMIC 20-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:TPS74201RGRR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	20-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Operating Temperature	-40°C~125°C TJ
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	20
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position	QUAD
Terminal Form	NO LEAD
Number of Functions	1
Terminal Pitch	0.5mm
Base Part Number	TPS74201
Current - Supply (Max)	1.5mA
Number of Outputs	1
Voltage - Input (Max)	5.5V
Output Type	Adjustable
Output Configuration	Positive
Current - Output	1.5A
Control Features	Enable, Power Good, Soft Start
Voltage - Output (Min/Fixed)	0.8V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	115μA
Voltage Dropout (Max)	0.12V @ 1.5A
PSRR	73dB ~ 42dB (1kHz ~ 300kHz)
Dropout Voltage1-Nom	0.055V
Output Voltage1-Min	0.796V
Voltage - Output (Max)	3.6V
Height	1mm
Length	3.5mm
Width	3.5mm
Thickness	900μm
RoHS Status	ROHS3 Compliant

TPS74201RGRR Product Details

TPS74201RGRR Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 20-VFQFN Exposed Pad package. There are 20 terminations on the gadget. The IC chip's output type is Adjustable. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C TJ degrees. This regulator's output function is configured to be Positive. Its current output stands at 1.5A. To ensure prompt, sufficient performance, this part features 1 outputs in total. The component's pin number remains 20. FYI, the basic part number for this IC regulator is TPS74201.
