Name: 111CNQ045ASM
Brand: Vishay Semiconductor Diodes Division
SKU: 111CNQ045ASM
Availability: InStock

new-10%

111CNQ045ASM

Manufacturer part number:111CNQ045ASM

Manufacturer:Vishay Semiconductor Diodes Division

Description:111CNQ045ASM datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:111CNQ045ASM Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Radial, Through Hole
Mounting Type	Through Hole
Package / Case	D-61-8-SM
Supplier Device Package	D-61-8-SM
Packaging	Bulk
Published	2012
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Capacitance	3.9nF
Voltage - Rated DC	45V
Current Rating	110A
Base Part Number	111CNQ045
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	1.5mA @ 45V
Voltage - Forward (Vf) (Max) @ If	610mV @ 55A
Max Reverse Leakage Current	1.5mA
Operating Temperature - Junction	-55°C~175°C
Max Surge Current	4kA
Voltage - DC Reverse (Vr) (Max)	45V
Current - Average Rectified (Io)	55A
Forward Voltage	610mV
Max Reverse Voltage (DC)	45V
Average Rectified Current	55A
Diode Configuration	1 Pair Common Cathode
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

111CNQ045ASM Product Details

111CNQ045ASM Overview

There will be no operation of this device when the forward voltage is set to 610mV.A surge current should be monitored and should not exceed 4kA.Array is possible to draw current from the part of 110A.This device has approximately 3.9nF farads of capacitance.When reverse biased, its maximal reverse leakage current is 1.5mA, which is the current flowing from that semiconductor device.
