Name: 83CNQ080ASM
Brand: Vishay Semiconductor Diodes Division
SKU: 83CNQ080ASM
Availability: InStock

new-10%

83CNQ080ASM

Manufacturer part number:83CNQ080ASM

Manufacturer:Vishay Semiconductor Diodes Division

Description:83CNQ080ASM datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:83CNQ080ASM Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Radial, Through Hole
Mounting Type	Through Hole
Package / Case	D-61-8-SM
Supplier Device Package	D-61-8-SM
Packaging	Bulk
Published	2010
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Capacitance	1.4nF
Voltage - Rated DC	80V
Current Rating	80A
Base Part Number	83CNQ080
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	1.5mA @ 80V
Voltage - Forward (Vf) (Max) @ If	1V @ 80A
Max Reverse Leakage Current	1.5mA
Operating Temperature - Junction	-55°C~175°C
Max Surge Current	7kA
Voltage - DC Reverse (Vr) (Max)	80V
Current - Average Rectified (Io)	80A
Max Reverse Voltage (DC)	80V
Average Rectified Current	80A
Diode Configuration	1 Pair Common Cathode
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

83CNQ080ASM Product Details

83CNQ080ASM Overview

We should be monitoring the surge current and keeping it below 7kA.The part can draw a current of 80A.An approximate capacitance of 1.4nF farads is present in this device.The maximum reverse leakage current from this semiconductor is 1.5mA, which corresponds to the reverse leakage current from that device when reverse biased.
