BY228GP-E3/73

Name: BY228GP-E3/73
Brand: Vishay Semiconductor Diodes Division
SKU: BY228GP-E3/73
Availability: InStock

new-10%

BY228GP-E3/73

Manufacturer part number:BY228GP-E3/73

Manufacturer:Vishay Semiconductor Diodes Division

Description:BY228GP-E3/73 datasheet pdf and Diodes - Rectifiers - Single product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:BY228GP-E3/73 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	22 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	DO-201AD, Axial
Number of Pins	2
Diode Element Material	SILICON
Packaging	Tape & Box (TB)
Published	2015
Series	Automotive, AEC-Q101
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	150°C
Min Operating Temperature	-65°C
Additional Feature	FREE WHEELING DIODE, HIGH RELIABILITY
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Terminal Form	WIRE
Peak Reflow Temperature (Cel)	NOT APPLICABLE
Reach Compliance Code	unknown
[email protected] Reflow Temperature-Max (s)	NOT APPLICABLE
Pin Count	2
Qualification Status	Not Qualified
Number of Elements	1
Element Configuration	Single
Speed	Standard Recovery >500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	5μA @ 1500V
Voltage - Forward (Vf) (Max) @ If	1.6V @ 2.5A
Case Connection	ISOLATED
Operating Temperature - Junction	-65°C~150°C
Application	HIGH VOLTAGE
Voltage - DC Reverse (Vr) (Max)	1500V
Forward Voltage	1.6V
Max Reverse Voltage (DC)	1.5kV
Average Rectified Current	2.5A
Number of Phases	1
Reverse Recovery Time	20 μs
Peak Reverse Current	5μA
Max Repetitive Reverse Voltage (Vrrm)	1.5kV
Capacitance @ Vr, F	40pF @ 4V 1MHz
Peak Non-Repetitive Surge Current	50A
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
