UGE18BCT-E3/45

  • UGE18BCT-E3/45 - UGE18BCT-E3/45 datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website
  • UGE18BCT-E3/45 - UGE18BCT-E3/45 datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

UGE18BCT-E3/45

UGE18BCT-E3/45

Vishay Semiconductor Diodes Division

UGE18BCT-E3/45 datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

SOT-23

UGE18BCT-E3/45 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Part StatusObsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 100V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 20A
Operating Temperature - Junction -65°C~150°C
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 18A
Reverse Recovery Time 30ns
Diode Configuration 1 Pair Common Cathode
RoHS StatusROHS3 Compliant
In-Stock:2316 items

UGE18BCT-E3/45 Product Details

UGE18BCT-E3/45 Overview




UGE18BCT-E3/45 Features



UGE18BCT-E3/45 Applications


There are a lot of Vishay Semiconductor Diodes Division UGE18BCT-E3/45 applications of rectifier diode array.

  • Free wheeling diode in low voltage converters
  • Rectifier for drives applications
  • Crowbar applications
  • General Rectification
  • Battery chargers
  • Rectifiers in switch mode power supplies (SMPS)
  • Rectifiers for UBS
