Name: VF30200C-E3/4W
Brand: Vishay Semiconductor Diodes Division
SKU: VF30200C-E3/4W
Price: 2.89000 USD
Availability: InStock

new-10%

VF30200C-E3/4W

Manufacturer part number:VF30200C-E3/4W

Manufacturer:Vishay Semiconductor Diodes Division

Description:VF30200C-E3/4W datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:VF30200C-E3/4W Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mount	Surface Mount, Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-3 Full Pack, Isolated Tab
Number of Pins	3
Diode Element Material	SILICON
Packaging	Tube
Published	2011
Series	TMBS®
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Max Operating Temperature	150°C
Min Operating Temperature	-20°C
Additional Feature	FREE WHEELING DIODE
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	unknown
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	3
Qualification Status	Not Qualified
Number of Elements	2
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	160μA @ 200V
Voltage - Forward (Vf) (Max) @ If	1.1V @ 15A
Forward Current	30A
Max Reverse Leakage Current	160μA
Operating Temperature - Junction	-40°C~150°C
Max Surge Current	250A
Application	EFFICIENCY
Forward Voltage	1.1V
Max Reverse Voltage (DC)	200V
Average Rectified Current	15A
Number of Phases	1
Peak Reverse Current	160μA
Max Repetitive Reverse Voltage (Vrrm)	200V
JEDEC-95 Code	TO-220AB
Peak Non-Repetitive Surge Current	250A
Diode Configuration	1 Pair Common Cathode
RoHS Status	ROHS3 Compliant

VF30200C-E3/4W Product Details

VF30200C-E3/4W Overview

This device will operate when the forward voltage is set to 1.1V.Array is important to monArrayor the surge current and make sure that Array does not exceed 250A.The device operates when the forward voltage is set to 30A.This device is powered with reverse voltage peak of 160μA V.The maximum reverse leakage current from a semiconductor device when reverse biased is 160μA.
