Name: VS-10ETF02PBF
Brand: Vishay Semiconductor Diodes Division
SKU: VS-10ETF02PBF
Availability: InStock

new-10%

VS-10ETF02PBF

Manufacturer part number:VS-10ETF02PBF

Manufacturer:Vishay Semiconductor Diodes Division

Description:VS-10ETF02PBF datasheet pdf and Diodes - Rectifiers - Single product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:VS-10ETF02PBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-2
Diode Element Material	SILICON
Packaging	Tube
Published	2015
JESD-609 Code	e3
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	MATTE TIN OVER NICKEL
Max Operating Temperature	150°C
Min Operating Temperature	-40°C
Additional Feature	FREE WHEELING DIODE
HTS Code	8541.10.00.80
JESD-30 Code	R-PSFM-T2
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	100μA @ 200V
Voltage - Forward (Vf) (Max) @ If	1.2V @ 10A
Case Connection	CATHODE
Forward Current	10A
Operating Temperature - Junction	-40°C~150°C
Max Surge Current	160A
Application	FAST SOFT RECOVERY
Max Reverse Voltage (DC)	200V
Average Rectified Current	10A
Number of Phases	1
Reverse Recovery Time	200 ns
Peak Reverse Current	100μA
Max Repetitive Reverse Voltage (Vrrm)	200V
JEDEC-95 Code	TO-220AC
Peak Non-Repetitive Surge Current	160A
Reverse Voltage	200V
Recovery Time	145 ns
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

VS-10ETF02PBF Product Details

VS-10ETF02PBF Overview

There is no reason to reverse the voltage at 200V.This device's average rectified current is zero volts.In this case, forward current can reach 10A.This is the maximum amount of 160A surge current that can be used.Based on the data chart, the peak reverse is 100μA.
