Name: 1146740000
Brand: Weidmüller
SKU: 1146740000
Price: 1.59000 USD
Availability: InStock

new-10%

1146740000

Manufacturer part number:1146740000

Manufacturer:Weidmüller

Description:1146740000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1146740000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2011
Series	Omnimate SL
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	Header, Male Pins, Shrouded (2 Side)
Number of Positions	3
Color	Orange
Number of Rows	1
Gender	Male
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	3
Insulation Height	0.335 8.51mm
Current Rating	24A
Termination Style	Solder
Approval Agency	cURus
UL Flammability Code	94V-0
Contact Tail Length	0.126 3.20mm
Number of Levels	1
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	90°, Right Angle
Hole Diameter	1.3 mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1146740000 Product Details

1146740000 Overview

Through Hole indicates that the device is mounted.To package the product, a Bulk case is used.It belongs to the Omnimate SL Series of products.Through Hole is mounting the part.This device runs at -50°C~100°C operating temperature.Several of the benefits of this part are also shared by other Header, Male Pins, Shrouded (2 Side) products.
