Name: 1290220000
Brand: Weidmüller
SKU: 1290220000
Price: 3.09000 USD
Availability: InStock

new-10%

1290220000

Manufacturer part number:1290220000

Manufacturer:Weidmüller

Description:1290220000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1290220000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mounting Type	Through Hole
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-50°C~120°C
Packaging	Bulk
Series	Omnimate S2C
Feature	Mating Flange, Solder Retention
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	4
Color	Black
Number of Rows	1
Voltage - Rated	150V
Pitch	0.138 3.50mm
Ingress Protection	IP20
Insulation Height	0.559 14.20mm
Current Rating	10A
Termination Style	Solder
Contact Tail Length	0.138 3.50mm
Contact Mating Finish	Tin
Voltage - IEC	200V
Positions Per Level	2
Header Orientation	Vertical
Current - IEC	13.4A
Hole Diameter	1.3 mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1290220000 Product Details

1290220000 Overview

Its mounting type is Through Hole.It is necessary to use a Bulk case for packaging the product.The product is part of the Omnimate S2C Series.It is more powerful in many ways due to its Mating Flange, Solder Retention feature.Operating temperature is -50°C~120°C.There are many benefits that this part shares with other Header, Male Pins, Shrouded (4 Side) products as well.
