Name: 1511160000
Brand: Weidmüller
SKU: 1511160000
Availability: InStock

new-10%

1511160000

Manufacturer part number:1511160000

Manufacturer:Weidmüller

Description:1511160000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1511160000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2004
Series	Omnimate SL
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Header
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	10
Color	Orange
Number of Rows	1
Gender	Male
HTS Code	8536.69.40.40
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	10
Orientation	Right Angle
Ingress Protection	IP20
Depth	12mm
Insulation Height	0.330 8.38mm
Termination Style	Solder
UL Flammability Code	94V-0
Contact Tail Length	0.126 3.20mm
Max Current Rating	10A
Number of Levels	1
Contact Mating Finish	Tin
Voltage - UL	300V
Current - UL	15A
Voltage - IEC	400V
Header Orientation	90°, Right Angle
Current - IEC	18A
Length	52.8mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	RoHS Compliant

1511160000 Product Details

1511160000 Overview

Packaging is in the form of Header.Mounting type is Through Hole.To package the product, a Bulk case is used.This product is from the Omnimate SL Series.Device runs at -50°C~100°C Operating Temperature.Many Header, Male Pins, Shrouded (4 Side) products share the same benefits as this part.
