Name: 1512960000
Brand: Weidmüller
SKU: 1512960000
Availability: InStock

new-10%

1512960000

Manufacturer part number:1512960000

Manufacturer:Weidmüller

Description:1512960000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1512960000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-20°C~100°C
Packaging	Bulk
Published	1998
Series	Omnimate SL
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (2 Side)
Color	Orange
Number of Rows	1
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	5
Orientation	Right Angle
Depth	12mm
Insulation Height	0.335 8.51mm
Termination Style	Solder
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.177 4.50mm
Max Current Rating	15A
Number of Levels	1
Current	15A
Contact Mating Finish	Tin
Voltage - IEC	250V
Header Orientation	90°, Right Angle
Current - IEC	12A
Number of Positions Per Level	5
Width	12mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1512960000 Product Details

1512960000 Overview

There is a Through Hole mounting type for the device.It has been determined that a Bulk case is necessary to package the product.This product is in the Omnimate SL Series.Through Hole represents the mounting point for the part.The device is operating at -20°C~100°C Operating Temperature.As with other Header, Male Pins, Shrouded (2 Side) products, this part has a lot of benefits.
