Name: 1660720000
Brand: Weidmüller
SKU: 1660720000
Price: 2.87000 USD
Availability: InStock

new-10%

1660720000

Manufacturer part number:1660720000

Manufacturer:Weidmüller

Description:1660720000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1660720000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate BL
JESD-609 Code	e3
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Termination	Screw
Type	Plug, Female Sockets
Number of Positions	3 (Mate), 6 (Input)
Color	Black
Number of Rows	1
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Orientation	Straight
Ingress Protection	IP20
Insulation Height	0.917 23.29mm
Termination Style	Screw - Clamping Yoke (Tension Sleeve)
Number of Contacts	3
UL Flammability Code	94V-0
Voltage	300V
Number of Levels	1 (Mate), 2 (Input)
Current	10A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	12-26 AWG
Voltage - IEC	400V
Torque - Screw	0.4-0.5 Nm (3.5-4.4 Lb-In)
Positions Per Level	3
Plug Wire Entry	90° and 270°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Current - IEC	14A
Screw Size	M2.5
Height	26.8mm
Length	15.2mm
Width	23.3mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1660720000 Product Details

1660720000 Overview

Free Hanging (In-Line) is the mounting type of the device.Packaged in a Bulk case.Omnimate BL Series product.With its Retention Latches (Non-Wire Side) feature, it is more powerful in many ways.Mounted by Cable, Free Hanging.This device runs at -50°C~100°C operating temperature.
