XC6SLX25T-4CSG324C

XC6SLX25T-4CSG324C

XC6SLX25T-4CSG324C

Xilinx Inc.

1.5mm mm FPGAs Spartan?-6 LXT Series 324-LFBGA, CSPBGA 0.8mm mm 324

SOT-23

XC6SLX25T-4CSG324C Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 324-LFBGA, CSPBGA
Operating Temperature0°C~85°C TJ
PackagingTray
Published 2008
Series Spartan®-6 LXT
JESD-609 Code e1
Part StatusObsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 324
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 1.14V~1.26V
Terminal Position BOTTOM
Terminal FormBALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch0.8mm
Reach Compliance Code unknown
[email protected] Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number XC6SLX25
Pin Count324
JESD-30 Code S-PBGA-B324
Number of Outputs 190
Qualification StatusNot Qualified
Power Supplies1.22.5/3.3V
Number of I/O 190
RAM Size 117kB
Number of Inputs 190
Programmable Logic TypeFIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 24051
Total RAM Bits 958464
Number of LABs/CLBs 1879
Height Seated (Max) 1.5mm
Length 15mm
Width 15mm
RoHS StatusRoHS Compliant
In-Stock:3033 items

XC6SLX25T-4CSG324C Product Details

XC6SLX25T-4CSG324C Overview


A 324-LFBGA, CSPBGA package is provided with this component. An FPGA of this type is made up of FIELD PROGRAMMABLE GATE ARRAY gates. Fpga chips is programmed wFpga chipsh 190 I/Os for transferring data in a more coherent manner. To form a fundamental building block, there are 24051 logic elements/cells. This FPGA part belongs to the family of Field Programmable Gate Arrays. FPGA modules can be attached to development boards using a Surface Mount-connector. In order for it to operate, the supply voltage must be 1.14V~1.26V . The Spartan?-6 LXT Series is one of the types of FPGAs that belong to this type. In order to ensure a safe and efficient operation, it is important to maintain a temperature within 0°C~85°C TJ at all times. A total of 190 outputs are incorporated into this device. Fpga chips is designed to maximiTraye space efficiency by containing the FPGA model in Tray. There are a total of 324 terminations. This device is equipped with 958464 RAM bits in terms of its RAM si958464e. Its base part number XC6SLX25 can be used to find parts that are related to it. The RAM si117kBe of this FPGA module reaches 117kB so as to guarantee the normal operation of the program during operation. This FPGA is built as an array of 1879 LABs/CLBs. According to its specifications, this FPGA will be able to work fantastically as long as it is mounted in Surface Mount. Powered by a 1.22.5/3.3V power supply, it can be operated by almost anyone. This device has a pin count of 324 in fpga semiconductor.

XC6SLX25T-4CSG324C Features


190 I/Os
Up to 958464 RAM bits

XC6SLX25T-4CSG324C Applications


There are a lot of Xilinx Inc. XC6SLX25T-4CSG324C FPGAs applications.

  • Automotive driver's assistance
  • ADAS
  • Consumer Electronics
  • Random logic
  • Enterprise networking
  • Video & Image Processing
  • Medical Electronics
  • Military DSP
  • Ecosystem
  • Electronic Warfare
