XCV150-6BG256C

XCV150-6BG256C

XCV150-6BG256C

Xilinx Inc.

2.55mm mm FPGAs Virtex? Series 256-BBGA 1.27mm mm 256

SOT-23

XCV150-6BG256C Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 256-BBGA
Number of Pins 256
Operating Temperature0°C~85°C TJ
PackagingTray
Published 2000
Series Virtex®
JESD-609 Code e0
Pbfree Code no
Part StatusObsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 256
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 2.375V~2.625V
Terminal Position BOTTOM
Terminal FormBALL
Peak Reflow Temperature (Cel) 225
Supply Voltage 2.5V
Terminal Pitch1.27mm
Reach Compliance Code not_compliant
[email protected] Reflow Temperature-Max (s) 30
Base Part Number XCV150
Pin Count256
Number of Outputs 180
Qualification StatusNot Qualified
Power Supplies1.2/3.62.5V
Number of I/O 180
RAM Size 6kB
Clock Frequency 333MHz
Programmable Logic TypeFIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 3888
Total RAM Bits 49152
Number of Gates164674
Number of LABs/CLBs 864
Combinatorial Delay of a CLB-Max 0.6 ns
Number of CLBs 864
Height Seated (Max) 2.55mm
Length 27mm
Width 27mm
RoHS StatusNon-RoHS Compliant
Lead Free Contains Lead
In-Stock:1459 items

XCV150-6BG256C Product Details

XCV150-6BG256C Overview


A 256-BBGA package is provided with this component. Fpga chips consists of FIELD PROGRAMMABLE GATE ARRAY elements. 180 I/Os are available for transferring data more efficiently. A fundamental building block consists of 3888 logic elements/cells. It is powered from a supply voltage of 2.5V. An FPGA part from the Field Programmable Gate Arrays family. The Surface Mount-slot connector on the FPGA module can be connected to the development board. There is a 2.375V~2.625V-volt supply voltage required for the device to operate. The Virtex? Series is one of the types of FPGAs that belong to this type. In order to ensure a safe and efficient operation, it is important to maintain a temperature within 0°C~85°C TJ at all times. There are 180 outputs incorporated in this device. As a space-saving measure, this FPGA model is contained within Tray. In total, it has a total of 256 terminations. Having a RAM bit size of 49152 means that this device will offer you a lot of memory. In order to find related parts, you can use its base part number XCV150. During the configuration of this FPGA module, the RAM si6kBe reaches 6kB to ensure that the program runs normally. The device is designed with 256 pins in total. Fpga electronics contains 864 LABs/CLBs in an array. Providing the FPGA is mounted in Surface Mount as per the specifications of the IC, then it should work perfectly according to its specifications. An external power supply of 1.2/3.62.5V is required to power the device. Among its basic building blocks, there are 164674 gates that are included in it. In addition to this, it has 256 pins. Usually, fpga semiconductor uses a 333MHz crystal. A CLB is a basic module that determines the architecture of a system.

XCV150-6BG256C Features


180 I/Os
Up to 49152 RAM bits
256 LABs/CLBs

XCV150-6BG256C Applications


There are a lot of Xilinx Inc. XCV150-6BG256C FPGAs applications.

  • Camera time adjustments
  • Industrial Ethernet
  • Artificial intelligence (AI)
  • Industrial IoT
  • Broadcast
  • Development Boards and Shields for Microcontrollers
  • Medical Applications
  • Defense Applications
  • Automotive advanced driver assistance systems (ADAS)
  • Wired Communications
