Molex

0395345010 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

SOT-23

0395345010 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialPhosphor Bronze
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Operating Temperature-40°C~115°C
PackagingBulk
Series Eurostyle ESE 39534
Feature Mating Flange
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Color Green
Pitch 0.200 5.08mm
Orientation Right Angle
Depth 18.2mm
Insulation Height 0.591 15.00mm
Reach Compliance Code unknown
Termination Style Screw - Rising Cage Clamp
Voltage 300V
Max Supply Voltage300V
Number of Levels 1
Current 18A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Contact Mating Finish Tin
Wire Gauge or Range - AWG 12-30 AWG
Torque - Screw 0.56 Nm (5.0 Lb-In)
Plug Wire Entry 180°
Wire Strip Length 6.5mm
Number of Positions Per Level 10
Length 60.6mm
Material Flammability Rating UL94 V-0
RoHS StatusROHS3 Compliant
In-Stock:1067 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$6.78000$6.78
10$5.39300$53.93
25$5.14080$128.52
50$4.68720$234.36
100$4.51080$451.08
250$4.00680$1001.7
500$3.75480$1877.4

0395345010 Product Details

0395345010 Overview


A Free Hanging (In-Line) mounting type is specified for the device.It's packaged in a Bulk case.Among the products in the Eurostyle ESE 39534 Series, it is one of the most popular.There are a number of advantages to its Mating Flange feature.In this case, Cable, Free Hanging mounts the part.There is no operating temperature for the device.In order for this chip to function properly, the supply voltage should not exceed 300V.As with other Plug, Female Sockets products, this part has a lot of benefits.

0395345010 Features


Eurostyle ESE 39534 series

0395345010 Applications


There are a lot of Molex 0395345010 Terminal Blocks applications.

  • Measuring & Control Technology
  • Electrical substations
  • Variable speed/frequency drivers
  • Military Technology
  • Embedded systems
  • Energy efficient lighting (LED)
  • Communication
  • Refrigeration control
  • All Electrical Machinery
  • LED municipal outdoor and street lighting
