Name: 14310913101000
Brand: HARTING
SKU: 14310913101000
Price: 3.73000 USD
Availability: InStock

new-10%

14310913101000

Manufacturer part number:14310913101000

Manufacturer:HARTING

Description:14310913101000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from HARTING stock available on our website

Case Package:SOT-23

Datasheet:14310913101000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Copper Alloy
Mount	Free Hanging, Panel
Mounting Type	Free Hanging (In-Line)
Material	Glass fibre, Polymer
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-40°C~125°C
Packaging	Bulk
Series	har-flexicon®
Feature	Latch Lock
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
Type	Plug, Female Sockets
Color	Black
Number of Rows	1
Gender	Receptacle
Voltage - Rated	160V
Subcategory	Headers and Edge Type Connectors
Pitch	0.100 2.54mm
Total Number of Contacts	9
Orientation	Vertical
Depth	14.2mm
Insulation Height	0.193 4.90mm
Current Rating	7.3A
Reference Standard	UL
Termination Style	Screwless - Spring Cage, Tension Clamp
Reliability	COMMERCIAL
Contact Style	SQ PIN-SKT
Contact Resistance	20mOhm
Voltage	160V
Polarization Key	POLARIZED HOUSING
Number of Levels	1
Current	6A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	20 AWG
Contact Pattern	RECTANGULAR
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	20-26 AWG
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.14-0.5mm2
Wire Strip Length	6mm
Number of Positions Per Level	9
Wire Size (Min)	24 AWG
Length	28.16mm
Width	4.9mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

14310913101000 Product Details

14310913101000 Overview

This device is mounted in the Free Hanging (In-Line) position.In order to package the product, a Bulk case is used.The product belongs to the har-flexicon? Series.It is more powerful in many ways due to its Latch Lock feature.By Free Hanging, Panel, the part is mounted.In this case, the device runs at -40°C~125°C Operating Temperature.In addition to its benefits, this part also shares many with the other products in the Plug, Female Sockets series.
