Name: IRFU120ZPBF
Brand: Infineon Technologies
SKU: IRFU120ZPBF
Availability: InStock

new-10%

IRFU120ZPBF

Manufacturer part number:IRFU120ZPBF

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 100V 8.7A I-PAK

Case Package:SOT-23

Datasheet:IRFU120ZPBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-251-3 Short Leads, IPak, TO-251AA
Number of Pins	3
Supplier Device Package	IPAK (TO-251)
Operating Temperature	-55°C~175°C TJ
Packaging	Tube
Published	2003
Series	HEXFET®
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Through Hole
Resistance	190MOhm
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Voltage - Rated DC	100V
Technology	MOSFET (Metal Oxide)
Current Rating	8.7A
Power Dissipation-Max	35W Tc
Power Dissipation	35W
Turn On Delay Time	8.3 ns
FET Type	N-Channel
Rds On (Max) @ Id, Vgs	190mOhm @ 5.2A, 10V
Vgs(th) (Max) @ Id	4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	310pF @ 25V
Current - Continuous Drain (Id) @ 25°C	8.7A Tc
Gate Charge (Qg) (Max) @ Vgs	10nC @ 10V
Rise Time	26ns
Drain to Source Voltage (Vdss)	100V
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Fall Time (Typ)	23 ns
Turn-Off Delay Time	27 ns
Continuous Drain Current (ID)	8.7A
Threshold Voltage	4V
Gate to Source Voltage (Vgs)	20V
Drain to Source Breakdown Voltage	100V
Dual Supply Voltage	100V
Input Capacitance	310pF
Recovery Time	36 ns
Drain to Source Resistance	190mOhm
Rds On Max	190 mΩ
Nominal Vgs	4 V
Height	6.22mm
Length	6.7056mm
Width	2.3876mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Lead Free	Lead Free
