Name: ATSAM3X4EA-AU
Brand: Microchip Technology
SKU: ATSAM3X4EA-AU
Price: 14.40000 USD
Availability: InStock

new

ATSAM3X4EA-AU

Manufacturer part number:ATSAM3X4EA-AU

Manufacturer:Microchip Technology

Description:256KB 256K x 8 FLASH ARM® Cortex®-M3 32-Bit Microcontroller SAM3X Series ATSAM3X 100 Pin 84MHz 1.8V 144-LQFP

Case Package:SOT-23

Datasheet:ATSAM3X4EA-AU Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	144-LQFP
Surface Mount	YES
Number of Pins	100
Supplier Device Package	144-LQFP (20x20)
Number of Terminals	144
Mounting Style	SMD/SMT
Data Converters	A/D 16x12b, D/A 2x12b
MSL	MSL 3 - 168 hours
Interfaces	CAN, ENET, I2C, I2S, SPI, SSI, UART, USB
Number of I/Os	103 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tray
Base Product Number	ATSAM3X
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	104
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	SAM3X
Published	2012
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	144
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Position	QUAD
Terminal Form	GULL WING
Supply Voltage	1.8V
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Frequency	84MHz
Base Part Number	ATSAM3X
JESD-30 Code	S-PQFP-G144
Qualification Status	Not Qualified
Operating Supply Voltage	3.6V
Power Supplies	1.8,3.3 V
Temperature Grade	INDUSTRIAL
Interface	CAN, EBI/EMI, Ethernet, I2C, IrDA, LIN, MMC, SPI, UART, USART, USB
Memory Size	256kB
Oscillator Type	Internal
Number of I/O	103
Speed	84MHz
RAM Size	68K x 8
Memory Type	FLASH, ROM
Voltage - Supply (Vcc/Vdd)	1.62V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M3
Peripherals	Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	256KB 256K x 8
Connectivity	CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, Memory Card, SPI, SSC, UART/USART, USB
Bit Size	32
Data Converter	A/D 16x12b; D/A 2x12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	1.6 mm
Number of Timers/Counters	1
Address Bus Width	24
Product Type	ARM Microcontrollers - MCU
ROM (words)	262144
Core Architecture	ARM
EEPROM Size	--
CPU Family	CORTEX-M3
External Data Bus Width	16
Number of UART Channels	5
RAM (bytes)	65536
Number of ADC Channels	16
ROM Programmability	FLASH
Number of PWM Channels	8
Number of DAC Channels	2
Product Category	ARM Microcontrollers - MCU
Device Core	ARM Cortex M3
Height	1.3mm
Length	20mm
Width	20mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

ATSAM3X4EA-AU Product Details

ATSAM3X4EA-AU Description

Atmel’s ATSAM3X4EA-AU is a member of a family of Flash microcontrollers based on the high-performance 32-bit ARM Cortex-M3 RISC processor. It operates at a maximum speed of 84 MHz and features up to 512 Kbytes of Flash and up to 100 Kbytes of SRAM. The peripheral set includes a High-Speed USB Host and Device port with embedded transceiver, an Ethernet MAC, 2x CANs, a High-Speed MCI for SDIO/SD/MMC, an External Bus Interface with NAND Flash controller, 5x UARTs, 2x TWIs, 4x SPIs, as well as 1 PWM timer, 9x general-purpose 32-bit timers, an RTC, a 12-bit ADC, and a 12-bit DAC.
