Name: MCP1711T-12I/OT
Brand: Microchip Technology
SKU: MCP1711T-12I/OT
Price: 0.50000 USD
Availability: InStock

new-10%

MCP1711T-12I/OT

Manufacturer part number:MCP1711T-12I/OT

Manufacturer:Microchip Technology

Description:Enable Fixed 0.95mm MCP1711 PMIC -- Series 5 SC-74A, SOT-753

Case Package:SOT-23

Datasheet:MCP1711T-12I/OT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	SC-74A, SOT-753
Surface Mount	YES
Supplier Device Package	SOT-23-5
Number of Terminals	5
Mounting Style	SMD/SMT
Supplier Package	SOT-23
Input Voltage Range	1.4 to 6 V
Maximum Input Voltage	6 V
Junction to Ambient	400 °C/W
Mounting	Surface Mount
Package Type	SOT-23
Operating Temp Range	-40C to 85C
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MCP1711
Mfr	Microchip Technology
Product Status	Active
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
RoHS	Details
Package Shape	RECTANGULAR
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Published	2016
Series	--
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
ECCN Code	EAR99
Type	LDO
Terminal Finish	Matte Tin (Sn) - annealed
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.95mm
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	MCP1711
Pin Count	5
JESD-30 Code	R-PDSO-G5
Function	LDO
Current - Supply (Max)	1.8μA
Number of Outputs	1
Voltage - Input (Max)	6V
Output Voltage	1.2V
Output Type	Fixed
Polarity	Positive
Operating Supply Current	800 nA
Output Configuration	Positive
Output Current	0.15 A
Current - Output	150mA
Quiescent Current	1.8(uA)
Control Features	Enable
Output Voltage 1	1.2V
Input Voltage (Min)	1.4(V)
Voltage - Output (Min/Fixed)	1.2V
Number of Regulators	1
Protection Features	--
Current - Quiescent (Iq)	1.27μA
Voltage Dropout (Max)	1.93V @ 150mA
PSRR	--
Seated Height-Max	1.45 mm
Dropout Voltage	1.41V
Product Type	LDO Voltage Regulators
Output Voltage1-Max	1.22 V
Output Voltage1-Min	1.18 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	0.15 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	1.93 V
Min Current Limit	150mA
Screening Level	Industrial
Operating Temperature TJ-Max	125 °C
Line Regulation	0.19 %/V
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	1.2 V
Load Regulation	50 mV
Product	LDO Voltage Regulators
Input Voltage	6(V)
Product Category	LDO Voltage Regulators
Length	2.9mm
Width	1.55 mm
RoHS Status	ROHS3 Compliant

MCP1711T-12I/OT Product Details

MCP1711T-12I/OT Overview

A Tape & Reel (TR) case is used to deliver the Voltage Regulated IC. A SC-74A, SOT-753 case is used for packaging. As you can see, the IC chip has 5 terminations. Regulator IC chip's output type is Fixed. The electronic part implements 1 regulators in total. In this Regulator IC chip, the operating temperature of Surface Mount varies. -40°C~85°C degrees is the operating temperature of the Voltage Regulator IC. There is one output function configured for this voltage regulator IC, and that is Positive. As far as its current output is concerned, it stands at 150mA. This chip has a total of 5 pins, which are arranged in a rectangular shape. It has 1 outputs to ensure that the performance of this regulator is prompt and sufficient. The dropout voltage of the regulator IC is 10 volts. For your information, this regulator's basic part number is MCP1711. The component shown here is a typical PMIC - Power Management ICs component. It is important to note that this device has a FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR regulator type. It operates in the 1.8(uA) Quiescent Current state. Among the -- Series, the IC voltage regulator is one of the most popular models. With a supply current of 800 nA, the regulator IC operates.
