Name: ED550/9DS
Brand: On Shore Technology Inc.
SKU: ED550/9DS
Price: 3.24000 USD
Availability: InStock

new-10%

ED550/9DS

Manufacturer part number:ED550/9DS

Manufacturer:On Shore Technology Inc.

Description:0.138 3.50mm Gray Bulk Polyamide (PA), Nylon Through Hole Vertical with Board Screw - Leaf Spring, Wire Guard 1 Levels 16-28 AWG ED550/DS

Case Package:SOT-23

Datasheet:ED550/9DS Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Material	Brass
Contact Plating	Brass
Mount	Through Hole
Mounting Type	Through Hole
Number of Pins	9
Housing Material	Polyamide (PA), Nylon
Contact Material - Plating	Brass
Clamp Material - Plating	Steel, Stainless
Operating Temperature	-30°C~105°C
Packaging	Bulk
Series	ED550/DS
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Number of Positions	9
Max Operating Temperature	105°C
Min Operating Temperature	-30°C
Color	Gray
Number of Rows	1
Pitch	0.138 3.50mm
Lead Pitch	3.5mm
Housing Color	Grey
Wire Gauge	16-28 AWG
Voltage	125V
Plating	Steel
Number of Levels	1
Current	6A
Wire Gauge (Max)	28 AWG
Wire Gauge (Min)	16 AWG
Torque - Screw	0.4 Nm (3.5 Lb-In)
Positions Per Level	9
Mating Orientation	Vertical with Board
Wire Termination	Screw - Leaf Spring, Wire Guard
Screw Thread	M2
Number of Positions Per Level	9
Height	6.5mm
Length	31.5mm
Width	8.2mm
RoHS Status	ROHS3 Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

ED550/9DS Product Details

ED550/9DS Overview

Through Hole is the type of mounting for the device.To package the product, a Bulk case is used.The product is a member of the ED550/DS Series.9 pins are present on the device.Use it when the temperature is below 105°C.Temperatures below -30°C are required for this device to operate.It is mounted by Through Hole.It operates at an operating temperature of -30°C~105°C.
