Name: OSTTE031104
Brand: On Shore Technology Inc.
SKU: OSTTE031104
Price: 0.38000 USD
Availability: InStock

new-10%

OSTTE031104

Manufacturer part number:OSTTE031104

Manufacturer:On Shore Technology Inc.

Description:0.276 7.00mm Bulk Polyamide (PA66), Nylon 6/6 Through Hole Horizontal with Board Screw - Leaf Spring, Wire Guard 1 Levels 16-26 AWG OSTTE

Case Package:SOT-23

Datasheet:OSTTE031104 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Plating	Brass, Tin
Mount	Through Hole
Mounting Type	Through Hole
Number of Pins	3
Housing Material	Polyamide (PA66), Nylon 6/6
Contact Material - Plating	Brass - Tin Plated
Clamp Material - Plating	Steel, Stainless
Screw Material - Plating	Steel - Zinc Plated
Operating Temperature	-40°C~115°C
Packaging	Bulk
Series	OSTTE
Feature	Interlocking (Side)
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Max Operating Temperature	115°C
Min Operating Temperature	-40°C
Pitch	0.276 7.00mm
Wire Gauge	16-26 AWG
Voltage	125V
Plating	Steel
Number of Levels	1
Current	10A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	16 AWG
Torque - Screw	0.2 Nm (1.7 Lb-In)
Positions Per Level	3
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Leaf Spring, Wire Guard
Screw Thread	M2
Number of Positions Per Level	3
RoHS Status	ROHS3 Compliant

OSTTE031104 Product Details

OSTTE031104 Overview

Its mounting type is Through Hole.Packaging is performed using a Bulk case.It is part of the OSTTE Series of products.3 pins are provided on the device.Whenever it's below 115°C, it's best to use it.The device must operate at a temperature of -40°C at all times.A number of features make it more powerful because of its Interlocking (Side) feature.Through Hole mounts the part.There is no operating temperature for the device.
