Name: LN21RPHL
Brand: Panasonic Electronic Components
SKU: LN21RPHL
Availability: InStock

new-10%

LN21RPHL

Manufacturer part number:LN21RPHL

Manufacturer:Panasonic Electronic Components

Description:LED RED DIFFUSED 5MM ROUND T/H

Case Package:SOT-23

Datasheet:LN21RPHL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Radial
Packaging	Bulk
Published	2001
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Color	Red
HTS Code	8541.40.20.00
Subcategory	Visible LEDs
Number of Functions	1
Terminal Pitch	2.54mm
Reach Compliance Code	unknown
Base Part Number	LN*1
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-25°C
Configuration	Standard
Voltage - Forward (Vf) (Typ)	2.2V
Viewing Angle	30 deg
Optoelectronic Device Type	SINGLE COLOR LED
Current - Test	15mA
Lens Style	Round with Domed Top
Lens Size	5mm T-1 3/4
Luminous Intensity	3 mcd
Lens Transparency	Diffused
Wavelength - Peak	700nm
Forward Current-Max	0.025A
Forward Voltage-Max	2.8V
Reverse Voltage-Max	4V
Diameter	5mm
Height	8.65mm
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

About LN21RPHL

The LN21RPHL from Panasonic Electronic Components is a high-performance microcontroller designed for a wide range of embedded applications. This component features LED RED DIFFUSED 5MM ROUND T/H.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the LN21RPHL, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
