Name: 1715400
Brand: Phoenix Contact
SKU: 1715400
Price: 4.12000 USD
Availability: InStock

new-10%

1715400

Manufacturer part number:1715400

Manufacturer:Phoenix Contact

Description:1715400 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1715400 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Packaging	Bulk
Published	2011
Series	COMBICON MC
Feature	Mating Flange
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Type	Plug, Female Sockets
Number of Positions	3
Color	Black
Number of Rows	1
Voltage - Rated	160V
Pitch	0.138 3.50mm
Orientation	Right Angle
Insulation Height	0.437 11.10mm
Current Rating	8A
Termination Style	Screw - Rising Cage Clamp
Voltage	300V
Max Supply Voltage	160V
Max Current Rating	8A
Number of Levels	1
Current	8A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	14 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	14-30 AWG
Torque - Screw	0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways	3
Safety Approval	CB; CCA; CUL; GOST; UL; VDE
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.14-1.5mm2
Wire Strip Length	7mm
Screw Size	M2
Radiation Hardening	No
RoHS Status	RoHS Compliant

1715400 Product Details

1715400 Overview

Currently, it is packaged in Screw.This device is mounted in the Free Hanging (In-Line) position.In order to package the product, a Bulk case is used.It's from the COMBICON MC Series.Several benefits come from the Mating Flange feature.Mounting of the part is based on Free Hanging.In order for this chip to function properly, the supply voltage should not exceed 160V.There are a number of benefits that this part has in common with other Plug, Female Sockets products.
