Name: 1738898
Brand: Phoenix Contact
SKU: 1738898
Price: 27.96000 USD
Availability: InStock

new

1738898

Manufacturer part number:1738898

Manufacturer:Phoenix Contact

Description:Bulk 0.138 3.50mm Green 2 Levels Free Hanging (In-Line) Plug, Female Sockets COMBICON FMCD Polyamide (PA), Nylon

Case Package:SOT-23

Datasheet:1738898 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Material	Polyamide, Tin
Housing Material	Polyamide (PA), Nylon
Weight	12.796011g
Packaging	Bulk
Published	2011
Series	COMBICON FMCD
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Connector Type	Socket
Type	Plug, Female Sockets
Number of Positions	22
Color	Green
Number of Rows	2
Gender	Female
Voltage - Rated	160V
Additional Feature	PA, UL 94V0
HTS Code	8536.69.40.40
Pitch	0.138 3.50mm
Depth	16mm
Insulation Height	0.630 16.00mm
Reach Compliance Code	unknown
Current Rating	8A
Termination Style	Screwless - Push-In Spring
Voltage	150V
Number of Levels	2
Current	8A
Wire Gauge (Max)	24 AWG
Wire Gauge (Min)	16 AWG
Number of Decks	1
Wire Gauge or Range - AWG	16-24 AWG
Voltage - IEC	320V
Number of Ways	11
Safety Approval	UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1.5mm2
Wire Strip Length	10mm
Number of Positions Per Level	11
Fastening Method	SPRING LOADED
Height	23mm
Length	22.9mm
Width	39.2mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1738898 Product Details

1738898 Overview

Currently, it is packaged in Socket.The mounting type of the device is Free Hanging (In-Line).A Bulk case is used to package the product.A product of the COMBICON FMCD Series, it belongs to the range of products of that series.Furthermore, there are other features available, such as PA, UL 94V0, to name a few.Free Hanging represents the mounting point for the part.As with other Plug, Female Sockets products, this part also offers a wide range of benefits.
