Name: 1766398
Brand: Phoenix Contact
SKU: 1766398
Price: 3.62000 USD
Availability: InStock

new-10%

1766398

Manufacturer part number:1766398

Manufacturer:Phoenix Contact

Description:1766398 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1766398 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	1.50003kg
Packaging	Bulk
Published	2010
Series	COMBICON GMSTBA
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	Header, Male Pins, Shrouded (4 Side)
Color	Green
Number of Rows	1
Voltage - Rated	400V
Additional Feature	PA, 94V-0
HTS Code	8536.69.40.40
Voltage - Rated DC	400V
Pitch	0.295 7.50mm
Orientation	Right Angle
Depth	12mm
Insulation Height	0.339 8.61mm
Current Rating	12A
Termination Style	Solder
Approval Agency	CSA, UL
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Current Rating	12A
Number of Levels	1
Current	10A
Number of Poles	7
Number of Decks	1
Current - UL	15A
Voltage - IEC	630V
Number of Ways	7
Safety Approval	UL
Header Orientation	90°, Right Angle
Length	52.5mm
Width	12mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1766398 Product Details

1766398 Overview

Through Hole is the type of mounting for the device.We pack the product in a Bulk case.Specifically, it is one of the products in the COMBICON GMSTBA Series.In addition, there are other features, such as PA, 94V-0, to mention just a few.Through Hole is the mounting point for the part.There are a number of benefits that this part has in common with other Header, Male Pins, Shrouded (4 Side) products.
