Name: 1777206
Brand: Phoenix Contact
SKU: 1777206
Price: 9.14000 USD
Availability: InStock

new

1777206

Manufacturer part number:1777206

Manufacturer:Phoenix Contact

Description:1777206 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1777206 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Weight	154.999997g
Packaging	Bulk
Published	2010
Series	COMBICON MSTBV
Feature	Mating and Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Color	Green
Number of Rows	1
Voltage - Rated	250V
Additional Feature	PBT, 94V-0
HTS Code	8536.69.40.40
Pitch	0.200 5.08mm
Orientation	Straight
Depth	8.6mm
Insulation Height	0.472 12.00mm
Reach Compliance Code	not_compliant
Current Rating	12A
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.154 3.90mm
Max Current Rating	12A
Number of Levels	1
Current	12A
Number of Decks	1
Voltage - IEC	630V
Number of Ways	15
Safety Approval	UL
Header Orientation	Vertical
Number of Positions Per Level	15
Height	15.9mm
Length	86.36mm
Width	86.36mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1777206 Product Details

1777206 Overview

It comes in Plug packaging.Its mounting type is Through Hole.Packaging for the product is carried out via a Bulk case.The product is a member of the COMBICON MSTBV Series.Furthermore, there are other features such as PBT, 94V-0, to name a few.It is more powerful in many ways due to its Mating and Mounting Flange feature.By Through Hole, the part is mounted.There are a lot of similarities between this part and other Header, Male Pins, Shrouded (4 Side) products.
