Name: 1778120
Brand: Phoenix Contact
SKU: 1778120
Price: 18.12000 USD
Availability: InStock

new

1778120

Manufacturer part number:1778120

Manufacturer:Phoenix Contact

Description:Bulk 0.300 7.62mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets COMBICON PC Polyamide (PA), Nylon

Case Package:SOT-23

Datasheet:1778120 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Material	Polyamide, Tin
Housing Material	Polyamide (PA), Nylon
Packaging	Bulk
Series	COMBICON PC
Published	2011
Feature	Latch Lock
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Connector Type	Screw, Socket
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	1kV
Additional Feature	STANDARD: UL 94V-0, PA
Pitch	0.300 7.62mm
Depth	19.7mm
Insulation Height	0.776 19.70mm
Reach Compliance Code	not_compliant
Current Rating	41A
Termination Style	Screw - Rising Cage Clamp
Voltage	600V
Number of Levels	1
Current	41A
Wire Gauge (Max)	8 AWG
Wire Gauge (Min)	24 AWG
Number of Decks	1
Wire Gauge or Range - AWG	8-24 AWG
Voltage - IEC	1kV
Torque - Screw	0.5-0.8 Nm (4.4-7.1 Lb-In)
Number of Ways	8
Safety Approval	CUL; EAC; UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-10mm2
Wire Strip Length	10mm
Number of Positions Per Level	8
Screw Size	M3
Wire Cross Section	6 mm2
Height	35.3mm
Length	35.5mm
Width	69.11mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant

1778120 Product Details

1778120 Overview

The packaging contains Screw, Socket.There is a Free Hanging (In-Line) mounting type for the device.This product is packaged in a case marked Bulk.Product number COMBICON PC belongs to the COMBICON PC Series.Further, there are features such as STANDARD: UL 94V-0, PA, to name only a few.In many ways, it is more powerful due to its Latch Lock feature.There is a Free Hanging mount on the part.There are a lot of similarities between this part and other Plug, Female Sockets products.
