1779453

1779453

1779453

Phoenix Contact

1779453 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1779453 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 749.788188g
PackagingBulk
Published 2010
Series COMBICON FRONT-MSTB
Feature Retention Latches (Non-Wire Side)
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Screw
Type Plug, Female Sockets
Color Green
Voltage - Rated 250V
Additional FeaturePOLYAMIDE, 94V-0
Pitch 0.197 5.00mm
Insulation Height 0.591 15.00mm
Current Rating12A
Termination Style Screw - Pressure Clip
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 12-30 AWG
Voltage - IEC 630V
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 6
Safety Approval UL; CSA
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.2-2.5mm2
Wire Strip Length 10mm
Current - IEC 12A
Number of Positions Per Level 6
Screw Size M2.5
Wire Cross Section 2.5 mm2
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
In-Stock:615 items

Pricing & Ordering

QuantityUnit PriceExt. Price
50$14.04000$702

1779453 Product Details

1779453 Overview


This product is packaged in a Screw cartonIt's mounted Free Hanging (In-Line).It has been determined that a Bulk case is necessary to package the product.The product is part of the COMBICON FRONT-MSTB Series.There are also other features such as POLYAMIDE, 94V-0, to name only a few.In many ways, its Retention Latches (Non-Wire Side) feature makes it more powerful.Free Hanging is used to mount the part.Many Plug, Female Sockets products share the same benefits as this part.

1779453 Features


COMBICON FRONT-MSTB series

1779453 Applications


There are a lot of Phoenix Contact 1779453 Terminal Blocks applications.

  • Military Technology
  • Datacom
  • Instrumentation
  • Medical technology
  • Industrial Automation
  • Anywhere power is distributed
  • LED municipal outdoor and street lighting
  • Automotive Electronics
  • Refrigeration control
  • Control panels
