3042803

3042803

3042803

Phoenix Contact

3042803 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

3042803 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 4.529999g
PackagingBulk
Published 2011
Series CLIPLINE ST-COMBI SP
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Connector Type IDC, IDT
Type Plug, Female Sockets
Color Green, Yellow
Voltage - Rated 800V
HTS Code8536.69.40.40
Insulation Height 1.634 41.50mm
Current Rating32A
Termination Style Screwless - Spring Cage, Tension Clamp
Voltage 600V
Number of Levels 1
Current 30A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 28 AWG
Wire Gauge or Range - AWG 10-28 AWG
Voltage - IEC 800V
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.08-6mm2
Wire Strip Length 10mm
Current - IEC 32A
Height 41.5mm
Length 21mm
Width 6.2mm
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
In-Stock:3208 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$3.425000$3.425
10$3.231132$32.31132
100$3.048238$304.8238
500$2.875696$1437.848
1000$2.712921$2712.921

3042803 Product Details

3042803 Overview


The product is packaged in IDC, IDT.Free Hanging (In-Line) is the mounting type for the device.We use a Bulk case to package the product.CLIPLINE ST-COMBI SP Series product.Mounted by Free Hanging.Other Plug, Female Sockets products benefit from this part as well.

3042803 Features


CLIPLINE ST-COMBI SP series

3042803 Applications


There are a lot of Phoenix Contact 3042803 Terminal Blocks applications.

  • Data Technology
  • Variable speed/frequency drivers
  • Blowers
  • Electrical substations
  • Military Technology
  • Communication
  • Transportation
  • Telecommunications
  • Embedded systems
  • Medical technology
