RT7270HZSP Overview
Using the Tape & Reel (TR) package, this voltage regulator optimizes the performance of the voltage regulator 12v. In this voltage regulator, there are a total of 8 terminations. The space-saving 8-SOIC (0.154, 3.90mm Width) Exposed Pad package is available for this voltage regulator. DC DC switching regulator is configured with 1 outputs. As you can see, this DC DC switching regulator generates Adjustable output on its output pins. Surface Mount-mounting is compatible with this switching regulator. During switching regulator operation, the operating temperature should remain at -40°C~85°C TA. The switching frequency of this DC-DC switching regulator reaches 340kHz. The regulator is capable of operating with a dc to dc voltage regulator's minimum input voltage of 4.5V. It is evident from the table below that adjusting voltage regulator's output voltage (Min/Fixed) is equal to 0.925V. DC DC switching regulator's maximum design flexibility comes from its output current of 3A. Voltage regulators' input voltage is limited to 18V. This voltage regulator is included in the Switching Regulator or Controllers subcategory. There are 8 pins that are used for the operation of the voltage regulator 12v. The output voltage of this voltage regulator 12v should at least be set at 925mV volts at all times. With a maximum output voltage of 15V, DC DC switching regulator has a very high efficiency.
RT7270HZSP Features
1 outputs
8 pins
