Name: 2SK2503TL
Brand: ROHM Semiconductor
SKU: 2SK2503TL
Availability: InStock

new-10%

2SK2503TL

Manufacturer part number:2SK2503TL

Manufacturer:ROHM Semiconductor

Description:MOSFET N-CH 60V 5A DPAK

Case Package:SOT-23

Datasheet:2SK2503TL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Plating	Copper, Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins	3
Transistor Element Material	SILICON
Operating Temperature	150°C TJ
Packaging	Tape & Reel (TR)
Published	1998
JESD-609 Code	e2
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
ECCN Code	EAR99
Resistance	135mOhm
Terminal Finish	TIN COPPER
Subcategory	FET General Purpose Power
Voltage - Rated DC	60V
Technology	MOSFET (Metal Oxide)
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Current Rating	5A
[email protected] Reflow Temperature-Max (s)	10
Pin Count	3
JESD-30 Code	R-PSSO-G2
Number of Elements	1
Power Dissipation-Max	20W Tc
Element Configuration	Single
Operating Mode	ENHANCEMENT MODE
Power Dissipation	20W
Turn On Delay Time	5 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	135m Ω @ 2.5A, 10V
Vgs(th) (Max) @ Id	2.5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds	520pF @ 10V
Current - Continuous Drain (Id) @ 25°C	5A Ta
Rise Time	20ns
Drive Voltage (Max Rds On,Min Rds On)	4V 10V
Vgs (Max)	±20V
Fall Time (Typ)	20 ns
Turn-Off Delay Time	50 ns
Continuous Drain Current (ID)	5A
Gate to Source Voltage (Vgs)	20V
Drain Current-Max (Abs) (ID)	5A
Drain to Source Breakdown Voltage	60V
Pulsed Drain Current-Max (IDM)	20A
Dual Supply Voltage	60V
Nominal Vgs	2.5 V
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
