Name: FTE-114-01-G-DV
Brand: Samtec Inc.
SKU: FTE-114-01-G-DV
Price: 5.61000 USD
Availability: InStock

new-10%

FTE-114-01-G-DV

Manufacturer part number:FTE-114-01-G-DV

Manufacturer:Samtec Inc.

Description:FTE Series 2-Row Header Solder Phosphor Bronze Bulk Surface Mount Gold Liquid Crystal Polymer (LCP) 28-Position Board to Board 0.055 1.40mm Height

Case Package:SOT-23

Datasheet:FTE-114-01-G-DV Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Mount	Surface Mount
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Housing Material	Plastic
Operating Temperature	-55°C~125°C
Packaging	Bulk
Series	FTE
Published	2013
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	28
Number of Rows	2
Gender	Male
Additional Feature	LOW PROFILE
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	2.7A per Contact
Total Number of Contacts	28
Terminal Pitch	0.8mm
Insulation Height	0.055 1.40mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.031 0.80mm
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Row Spacing - Mating	0.047 (1.20mm)
Shrouding	Unshrouded
Number Of PCB Rows	2
Lead Pitch	800μm
Contact Length - Mating	0.075 1.90mm
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Housing Color	Black
Height	1.38mm
Length	11.2mm
Width	3.05mm
Plating Thickness	10μin
Contact Finish Thickness - Mating	10.0μin 0.25μm
Contact Finish Thickness - Post	3.00μin 0.076μm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

FTE-114-01-G-DV Product Details

FTE-114-01-G-DV Overview

Packaging is Header.Surface Mount is the mounting type.Packaging for the product is carried out via a Bulk case.As a product of the FTE Series, it can be found in this category.There are also other features such as LOW PROFILE, to name only a few.In this case, Surface Mount mounts the part.The device is operating at -55°C~125°C Operating Temperature.
