Name: 1986715-9
Brand: TE Connectivity AMP Connectors
SKU: 1986715-9
Price: 128.51000 USD
Availability: InStock

new

1986715-9

Manufacturer part number:1986715-9

Manufacturer:TE Connectivity AMP Connectors

Description:0.591 15.00mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw 1 Levels 1-20 AWG

Case Package:SOT-23

Datasheet:1986715-9 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	4 Weeks
Contact Material	Brass
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Contact Material - Plating	Copper Alloy - Tin Plated
Clamp Material - Plating	Steel - Tin Plated
Screw Material - Plating	Steel - Nickel Plated
Operating Temperature	-40°C~110°C
Packaging	Bulk
Published	2012
Feature	Flange (Mounting)
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Connector Type	Receptacle
Number of Positions	9
Max Operating Temperature	110°C
Min Operating Temperature	-40°C
Color	Green
Number of Rows	2
Voltage - Rated	600V
Pitch	0.591 15.00mm
Orientation	Straight
Current Rating	135A
Number of Contacts	9
Housing Color	Green
Lead Length	5mm
Wire Gauge	1-20 AWG
Voltage	600V
ELV	Compliant
Max Current Rating	130A
Plating	Steel, Tin
Number of Levels	1
Current	130A
Wire Gauge (Max)	20 AWG
Wire Gauge (Min)	20 AWG
Torque - Screw	2.1-2.5 Nm (1.5-1.8 LbIn)
Positions Per Level	9
Mating Orientation	Horizontal with Board
Wire Termination	Screw
Screw Thread	M5
Number of Positions Per Level	9
Max Supply Voltage (AC)	600V
Length - Tail	5mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

1986715-9 Product Details

1986715-9 Overview

You get it in Receptacle packaging.Mounting type Through Hole is selected for the device.Packaged in a Bulk case.Using it at a temperature below 110°C is ideal.A minimum temperature of -40°C is needed for this device.This feature renders it more powerful in a number of ways because of its Flange (Mounting) feature.There's a Through Hole mount on the part.Device runs in -40°C~110°C operating temperature.
