Name: U20CCT-E3/4W
Brand: Vishay Semiconductor Diodes Division
SKU: U20CCT-E3/4W
Availability: InStock

new-10%

U20CCT-E3/4W

Manufacturer part number:U20CCT-E3/4W

Manufacturer:Vishay Semiconductor Diodes Division

Description:U20CCT-E3/4W datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:U20CCT-E3/4W Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	19 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-3
Number of Pins	3
Diode Element Material	SILICON
Packaging	Tube
Published	2011
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Additional Feature	FREE WHEELING DIODE
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Terminal Position	SINGLE
Pin Count	3
Number of Elements	2
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	15μA @ 150V
Voltage - Forward (Vf) (Max) @ If	1V @ 10A
Forward Current	20A
Operating Temperature - Junction	-55°C~150°C
Max Surge Current	100A
Application	EFFICIENCY
Max Reverse Voltage (DC)	150V
Average Rectified Current	10A
Number of Phases	1
Reverse Recovery Time	80 ns
Peak Reverse Current	15μA
Max Repetitive Reverse Voltage (Vrrm)	150V
JEDEC-95 Code	TO-220AB
Peak Non-Repetitive Surge Current	100A
Reverse Voltage	150V
Diode Configuration	1 Pair Common Cathode
Recovery Time	80 ns
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

U20CCT-E3/4W Product Details

U20CCT-E3/4W Overview

Keeping the surge current under 100A and preventing it from exceeding it should be the rule.There will be no operation of this device when the forward voltage is set to 20A.The reverse voltage peak of this device is 15μA.
