Name: VS-HFA06PB120PBF
Brand: Vishay Semiconductor Diodes Division
SKU: VS-HFA06PB120PBF
Availability: InStock

new-10%

VS-HFA06PB120PBF

Manufacturer part number:VS-HFA06PB120PBF

Manufacturer:Vishay Semiconductor Diodes Division

Description:DIODE GEN PURP 1.2KV 6A TO247AC

Case Package:SOT-23

Datasheet:VS-HFA06PB120PBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Radial, Through Hole
Mounting Type	Through Hole
Package / Case	TO-247-2
Number of Pins	2
Diode Element Material	SILICON
Packaging	Tube
Published	2009
Series	HEXFRED®
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Additional Feature	LOW NOISE
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Peak Reflow Temperature (Cel)	NOT APPLICABLE
Reach Compliance Code	unknown
[email protected] Reflow Temperature-Max (s)	NOT APPLICABLE
Pin Count	2
Qualification Status	Not Qualified
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	5μA @ 1200V
Voltage - Forward (Vf) (Max) @ If	3V @ 6A
Case Connection	CATHODE
Forward Current	8A
Operating Temperature - Junction	-55°C~150°C
Max Surge Current	80A
Output Current-Max	6A
Application	EFFICIENCY
Voltage - DC Reverse (Vr) (Max)	1200V
Forward Voltage	3.9V
Max Reverse Voltage (DC)	1.2kV
Average Rectified Current	6A
Number of Phases	1
Reverse Recovery Time	130 ns
Peak Reverse Current	5μA
Max Repetitive Reverse Voltage (Vrrm)	1.2kV
Peak Non-Repetitive Surge Current	80A
Reverse Voltage	1.2kV
Max Forward Surge Current (Ifsm)	80A
Recovery Time	130 ns
Natural Thermal Resistance	0.5 °C/W
Height	20.7mm
Length	15.9mm
Width	5.3mm
RoHS Status	ROHS3 Compliant

About VS-HFA06PB120PBF

The VS-HFA06PB120PBF from Vishay Semiconductor Diodes Division is a high-performance microcontroller designed for a wide range of embedded applications. This component features DIODE GEN PURP 1.2KV 6A TO247AC.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the VS-HFA06PB120PBF, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
