Name: 1499560000
Brand: Weidmüller
SKU: 1499560000
Price: 5.11000 USD
Availability: InStock

new-10%

1499560000

Manufacturer part number:1499560000

Manufacturer:Weidmüller

Description:1499560000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1499560000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polybutylene Terephthalate (PBT), Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate BL
JESD-609 Code	e3
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Type	Plug, Female Sockets
Color	Orange
Number of Rows	1
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	2
Orientation	Straight
Depth	31.8mm
Insulation Height	0.480 12.20mm
Current Rating	15A
Termination Style	Screw - TOP Clamp
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Voltage	300V
Max Supply Voltage	300V
Max Current Rating	10A
Number of Levels	1
Current	17A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	14 AWG
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	14-26 AWG
Voltage - IEC	400V
Torque - Screw	0.4-0.5 Nm (3.5-4.4 Lb-In)
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Current - IEC	27A
Number of Positions Per Level	2
Screw Size	M2.5
Stripping Length	13mm
Length	10.16mm
Width	31.1mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1499560000 Product Details

1499560000 Overview

It's mounted Free Hanging (In-Line).This product is packaged in a case marked Bulk.A member of the Omnimate BL Series.With its Retention Latches (Non-Wire Side) feature, it is more powerful in many ways.There is a mounting hole at Cable, Free Hanging.Device runs at -50°C~100°C Operating Temperature.This chip shouldn't have a supply voltage over 300V.It is a part that shares many benefits with other products from the Plug, Female Sockets line.
