Name: 1625040000
Brand: Weidmüller
SKU: 1625040000
Price: 0.98000 USD
Availability: InStock

new-10%

1625040000

Manufacturer part number:1625040000

Manufacturer:Weidmüller

Description:1625040000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1625040000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (2 Side)
Number of Positions	3
Color	Orange
Number of Rows	1
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.300 7.62mm
Total Number of Contacts	3
Depth	8.5mm
Insulation Height	0.472 12.00mm
Current Rating	16A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.126 3.20mm
Max Current Rating	15A
Number of Levels	1
Current	10A
Number of Poles	3
Contact Mating Finish	Tin
Voltage - IEC	800V
Header Orientation	Vertical
Current - IEC	18.5A
Hole Diameter	1.3 mm
Length	22.66mm
Width	8.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1625040000 Product Details

1625040000 Overview

A Through Hole mounting type is specified for the device.An orange Bulk case is used to package the product.A member of the Omnimate SL Series.There's a Through Hole mount on the part.It runs at -50°C~100°C Operating Temperature.In addition to its benefits, this part also shares many with the other products in the Header, Male Pins, Shrouded (2 Side) series.
