Name: 1727590000
Brand: Weidmüller
SKU: 1727590000
Price: 13.02000 USD
Availability: InStock

new

1727590000

Manufacturer part number:1727590000

Manufacturer:Weidmüller

Description:1727590000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1727590000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2009
Series	Omnimate B2L
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Termination	Crimp
Type	Plug, Female Sockets
Color	Orange
Number of Rows	2
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.138 3.50mm
Orientation	Straight
Ingress Protection	IP20
Depth	20.6mm
Insulation Height	0.618 15.70mm
Termination Style	Screwless - Spring Cage, Tension Clamp
Number of Contacts	12
UL Flammability Code	94V-0
Insulation Resistance	1MOhm
Voltage	150V
Max Supply Voltage	150V
Max Current Rating	10A
Number of Levels	2
Current	10A
Wire Gauge (Max)	22 AWG
Wire Gauge (Min)	16 AWG
Contact Mating Finish	Tin
Voltage - UL	300V
Wire Gauge or Range - AWG	16-28 AWG
Voltage - IEC	200V
Positions Per Level	6
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1mm2
Wire Strip Length	7mm
Current - IEC	10.3A
Length	21mm
Width	20.6mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1727590000 Product Details

1727590000 Overview

Mounting type is Free Hanging (In-Line).To package the product, a Bulk case is used.The product belongs to the Omnimate B2L Series.The part is mounted by Cable, Free Hanging.-50°C~100°C Operating Temperature is the default.You should not supply this chip with more voltage than 150V.It shares many benefts with other Plug, Female Sockets products.
