Name: 1837640000
Brand: Weidmüller
SKU: 1837640000
Price: 2.66000 USD
Availability: InStock

new-10%

1837640000

Manufacturer part number:1837640000

Manufacturer:Weidmüller

Description:1837640000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1837640000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Shell Material	GLASS FILLED LIQUID CRYSTAL POLYMER
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate SL
JESD-609 Code	e3
Feature	Mating and Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Type	Header, Male Pins, Shrouded (4 Side)
Color	Black
Gender	Male
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	3
Orientation	Right Angle
Depth	12mm
Insulation Height	0.335 8.51mm
Current Rating	15A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Empty Shell	NO
Contact Tail Length	0.126 3.20mm
Max Current Rating	10A
Number of Levels	1
Number of Poles	3
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	90°, Right Angle
Current - IEC	27.5A
Hole Diameter	1.4 mm
Length	25.4mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1837640000 Product Details

1837640000 Overview

There is a Through Hole mounting type for the device.Packaging for the product is carried out via a Bulk case.Among the products in the Omnimate SL Series, it is one of the most popular.A number of features make the Mating and Mounting Flange feature more powerful.Part Through Hole is mounted to the part.-50°C~100°C Operating Temperature is the default operating temperature for the device.With this part, you get a lot of benefits that you won't find in other Header, Male Pins, Shrouded (4 Side) products.
