1015462

1015462

1015462

Phoenix Contact

1015462 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1015462 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Contact MaterialNOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Operating Temperature-40°C
PackagingBulk
Series COMBICON PTCM
JESD-609 Code e3
Feature Latch Lock
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Type Plug Housing for Female Sockets
Number of Positions 4
Color White
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.098 2.50mm
Total Number of Contacts 4
Insulation Height 0.154 3.90mm
Termination Style Crimp
Empty Shell NO
Number of Levels 1
Contact Finish Termination Tin (Sn)
Voltage - UL 150V
Wire Gauge or Range - AWG 18-22 AWG
Voltage - IEC 160V
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.14-0.75mm2
Wire Strip Length 4.1-4.5mm
Current - IEC 6A
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
In-Stock:22091 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.349868$0.349868
10$0.330065$3.30065
100$0.311382$31.1382
500$0.293756$146.878
1000$0.277128$277.128

1015462 Product Details

1015462 Overview


Free Hanging (In-Line) is the mounting type.Packaging for the product is carried out via a Bulk case.COMBICON PTCM Series product.Several benefits come from the Latch Lock feature.This device operates at a temperature of -40°C.As with other Plug Housing for Female Sockets products, this part has a lot of benefits.

1015462 Features


COMBICON PTCM series

1015462 Applications


There are a lot of Phoenix Contact 1015462 Terminal Blocks applications.

  • Automotive Electronics
  • Refrigeration control
  • Measuring & Control Technology
  • Communication
  • Control panels
  • LED municipal outdoor and street lighting
  • Datacom
  • Electrical substations
  • All Electrical Machinery
  • Medical technology
