Name: 1727081
Brand: Phoenix Contact
SKU: 1727081
Price: 6.19000 USD
Availability: InStock

new-10%

1727081

Manufacturer part number:1727081

Manufacturer:Phoenix Contact

Description:0.150 3.81mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Rising Cage Clamp 1 Levels 16-30 AWG COMBICON MKDS

Case Package:SOT-23

Datasheet:1727081 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon
Weight	4.759998g
Packaging	Bulk
Series	COMBICON MKDS
Published	2001
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Connector Type	Screw
Color	Green
Number of Rows	1
Voltage - Rated	300V
Pitch	0.150 3.81mm
Orientation	Straight
Depth	7.3mm
Current Rating	13.5A
Voltage - Rated AC	160V
Approval Agency	CB, CSA, UL, cULus
Lead Pitch	3.81mm
Number of Contacts	9
Wire Gauge	16-30 AWG
Max Current Rating	13.5A
Number of Levels	1
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	16 AWG
Wire/Cable Gauge	26 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways	9
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Rising Cage Clamp
Screw Thread	M2
Stripping Length	5mm
Height	12mm
Length	7.3mm
Width	34.28mm
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1727081 Product Details

1727081 Overview

It comes in Screw packaging.The device's mounting type is Through Hole.In order to package the product, a Bulk case is used.It belongs to the COMBICON MKDS Series of products.The part is mounted by Through Hole.
