Name: 1756298
Brand: Phoenix Contact
SKU: 1756298
Price: 4.19000 USD
Availability: InStock

new-10%

1756298

Manufacturer part number:1756298

Manufacturer:Phoenix Contact

Description:1756298 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1756298 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Contact Plating	Tin
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA), Nylon
Weight	1.999889kg
Packaging	Bulk
Published	2011
Series	COMBICON MSTB
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Screw, Socket
Type	Plug, Female Sockets
Color	Black
Number of Rows	1
Voltage - Rated	250V
Pitch	0.197 5.00mm
Orientation	Right Angle
Insulation Height	0.591 15.00mm
Current Rating	12A
Termination Style	Screw - Rising Cage Clamp
Number of Contacts	4
Voltage	300V
Max Supply Voltage	250V
Max Current Rating	12A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Voltage - IEC	630V
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	4
Safety Approval	UL; CSA
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Screw Size	M3
Height	18.2mm
Length	15mm
Width	20mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1756298 Product Details

1756298 Overview

Screw, Socket packaging is included.Mounting type Free Hanging (In-Line) is selected for the device.An Bulk case is utilized for packaging the product.Product number COMBICON MSTB belongs to the COMBICON MSTB Series.A number of benefits can be derived from the Retention Latches (Non-Wire Side) feature of this application.By Cable, Free Hanging, the part is mounted.A supply voltage of 250V is recommended for this chip.Several of the benefits of this part are also shared by other Plug, Female Sockets products.
